Infinite Optical System Motorized Auto-Focus Microscope from China manufacturer

Infinite Optical System Motorized Auto-Focus Microscope

Price:	1.0 USD
Payment Terms:	T/T
Place of Origin:	Beijing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: BS-2080D

Brand Name: BestScope

BS-2080D is a high level automatic microscope, it is mainly used in laboratories, hospitals and universities for scientific and medical research.

Introduction

BS-2080D Motorized Auto-focus Microscope has integrated the advantages of modern aesthetics and the edge of disciplines to achieve the automation of microscopes in laboratory. High quality infinite optical system and automatic controlling make your lab work more enjoyable. With a protection box, it can be used for remote diagnosis, pathological analysis for some infectious or virose specimens.

Features

1. With four motors drive, objective nosepiece, stage with X, Y, Z directions can be controlled manually or motorized.

2. With advanced digital illumination adjustment technology, brightness of halogen lamp has been divided into 100 steps(0-99).

3. 3.2 Megapixels camera system, USB 2.0 plugs and play; real-time preview is up to 30 frames/ sec.

4. High precision stage, quickly capture the clearest images by auto-focus. Automatically slide scanning, recognizing are controlled by the computer.

5. With built-in dynamic focusing system, realize the laboratory microscopy automation. With network remote control system, it can be used in medical diagnosis, pathological analysis and real-time teaching etc.

Applications

BS-2080D is a high level automatic microscope, it is mainly used in laboratories, hospitals and universities for

scientific and medical research. It can be used for medical diagnosis, pathological analysis and real-time

teachingetc, it also can be used for remote diagnosis. With a protection box, It can be used for remote

diagnosis, pathological analysis for some infectious or virose specimens.

Specifications

Model		BS-2080D
Optical System	Infinite Optical System	●
Viewing Head	Seidentopf Trinocular Head, Inclined at 30°, Interpupillary 48-75mm	●
Camera	3.2 Mega Pixels CMOS sensor	●
	Resolution: 2048×1536	●
	Pixel size: 3.2μm × 3.2μm	●
	Maximum frame rate: 2048×1536 12f/s 1600×1200 20f/s 1280×1024 27f/s 1024×768 43f/s	●
	Sensitivity: 1.0V/lux-sec(550nm)	●
	Exposure: Manual / auto exposure, time adjustable	●
	SNR: >43dB	●
Eyepiece	Extral wide field eyepiece EW10×/22, eyepiece tube Φ30mm	●
Nosepiece	Quintuple Nosepiece	●
Objective	Infinite Plan Achromatic Objective 4×, 10×, 20×, 40×, 100×	●
Stage	Precision leading screw stage, accuracy is 1um	●
Condenser	Swing out Condenser NA0.9/0.25	●
Filter	Blue and Green filter	●
Illumination	Halogen Lamp 24V/100W	●
Control System	The control box of BS-2080D Motorized Auto-focus Microscope	●
	The control software of BS-2080D Motorized Auto-focus Microscope	●
	Image analysis Software	●
	USB DOG	○
	Computer	○
G.W & Dimension	65cm * 46cm * 44cm, 30kg	●
