Inverted Fluorescent Biological Microscope With Infinitive Optical System

Price:	1.0 USD
Payment Terms:	T/T
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: BS-7020

Brand Name: BestScope

BS-7020 Inverted Fluorescent Biological Microscope is specifically designed for the observation of cell culture.

Introduction

BS-7020 inverted fluorescence microscope uses ultraviolet as the light source, objects which are radiated then fluoresce, and then the shape of an object and its location can be observed under the microscope. BS-7020 Inverted Fluorescent Biological Microscope is specifically designed for the observation of cell culture. Excellent high resolution fluorescent objectives provide high quality fluorescent images. Infinite Optical System gives excellent Optical performance. This microscope can be your best assistant in laboratory research.

Features

1. Excellent fluorescent image with high resolution fluorescent objectives.

2. Protect the light leak with advanced lamp housing.

3. Excellent Optical Function with Infinitive Optical System.

4. Innovative Stand structure, Sharp Image Display, Convenient and Special for Viewing Incubating Cell Tissue.

5. More stable power supply, digital display and timer.

Application area

BS-7020 Inverted Fluorescent Biological Microscope is specifically designed for the observation of cell culture. It is widely used in disease examination, immune diagnosis and laboratory research.

Specification

Model			BS-7020
Optical System	Infinite Optical System		●
Viewing Head	Seidentopf Trinocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary Distance 48-75mm		●
Eyepiece	Wide Field Eyepiece WF10×/ 22, Eyepiece Tube Diameter 30mm		●
	Wide Field Eyepiece WF15×/ 16		○
	Wide Field Eyepiece WF20×/ 12		○
Objective	LWD(Long Working Distance) Infinite Plan Achromatic Objective 4×/0.1,WD 18mm		●
	LWD(Long Working Distance) Infinite Plan Achromatic Phase Objective	10×/ 0.25, WD 6mm	●
		20×/ 0.4, WD 3.1mm	●
		40×/ 0.55, WD 2.2mm	●
	Lamp House Adjustment Objective		○
Nosepiece	Backward Quintuple Nosepiece		●
Condenser	ELWD(Extra Long Working Distance) Condenser NA 0.3, LWD 72mm (Without Condenser 150mm)		●
Centering Telescope	Centering Telescope (Φ30mm)		●
Phase Annulus	10×, 20×, 40× Phase Annulus Plate(Center Adjustable)		●
Stage	Plain Stage 170×230mm		●
	Glass Insert		●
	Attachable Mechanical Stage, X,Y Coaxial Control, Moving Rang120mm×80mm		●
	Auxiliary Stages 70mm×180mm		●
	Terasaki Holder		●
	Φ38mm Petri Dish Holder		●
	Φ54mm Slide Glass Holder		●
Focusing	Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range up 4.5mm, down 4.5mm		●
Illumination	Halogen Lamp 6V/30W, Brightness Adjustable		●
Filter	Blue, Green and Ground Glass, Diameter 45mm		●
Accessories	Photo tube Attachment(used to connect microscope adaptor and camera)		○
	C Mount(Used to directly connect to a digital camera)		○
	Epi-Fluorescent Attachment		○

Fluorescence attachment specification

Reflected Light Source		Excitation	Dichroic Mirror	Barrier Filter
	Blue excitation	BP460~490	DM500	BA520	●
	Blue excitation (B1)	BP460~495	DM505	BA510-550	○
	Green excitation	BP480~550	DM570	BA590	●
	Ultraviolet excitation	BP330~385	DM400	BA420	○
	Violet excitation	BP400~410	DM455	BA455	○
Lamp	100W HBO Ultra Hi-voltage Spherical Mercury Lamp				●
Protection barrier	Barrier to Resist the Ultraviolet Light				●
Power Supplier	Power Supplier NFP-1, 220V/ 110V interchangeable, Digital Display				●
Immersion Oil	Fluorescent Free Oil				●
Filter	Neutral ND25/ ND6 Filter				○
Centering Plate					●
Dimension& G.W.	46.5cm39.5cm64cm, 18kg				●
