21X - 135X Magnification Digital Monocular Microscope with Camera and Complete Accessories

Price:	1.0 USD
Payment Terms:	T/T
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: BS-1020D

Brand Name: BestScope

Delivery Date: 3 weeks

BS-1020D digital monocular microscope adopts high-quality optical systems.

Introduction
BS-1020D digital monocular microscope adopts high-quality optical systems. With characteristics of high-resolution, wide field of view and high zoom ratio. Simple to operate, can realize electrical zoom and focus adjust (optional), as well as electrical converse of observing angle. Ultra-high brightness LED lighting, the life can achieve 20,000 hours. The microscope needs a digital camera.

Applications
With excellent performance, complete accessories, simple and easy to operate, BS-1020D is widely used in electronic industry, small precision parts inspection, assembly, repair, especially for observation of surface structure, it also can be applied to biological anatomy, jewelry inspection and schools academic use(with special stand).

Features
1. Magnification standard 21X ~ 135X, the maximum can be 5X ~ 1080X, zoom magnification. External light source (LED light) needed.
2. Measurement software: point-to- point straight-line distance, three-point Circle, radius, perimeter, area, angle, perimeter of the polygon, area measurement.

3. Alternative objective lens and eyepiece, so as to obtain a multiple magnification.
4. With modular structure, compact and complete accessories, BS-1020D is widely used in microelectronics manufacturing and testing industry, especially for high-precision test and inspection industry.

Specification
Digital Part:
1. Model: BS-1020D(130), the digital camera is BUC1-130C, please view the specification of BUC1-130C for the technical details.
2. Model: BS-1020D(320), the digital camera is BUC1-320C, please view the specification of BUC1-320C for the technical details.
2. Model: BS-1020D(500), the digital camera is BUC1-500C, please view the specification of BUC1-500C for the technical details.

Optical Part:
Eyepiece: 0.5× (standard) Objective: 1× (standard)
Standard magnification: 20×-135×
0.7×-4.5× zoom magnification(zoom position can be choose)Zoom Ratio:1:6.6With eyepiece and objectives, optical magnification range: 0.21×-18×
Field of view: 0.3mm ~ 77mmWorking distance: 10mm-333mm, 1× Objective: 96mm

Eyepiece

Eyepiece	0.35×	0.5×	0.75×	1×	1.5×	2×
Focus length(mm)	67	90	135	10	270	360
Design length(mm)	76	97	103	130	189	252
Field of view angle	7.6

Objective

Objective	0.3×	0.5×	0.75×	1×	1.5×	2×
Focus length(mm)	333	200	133	100	67	50
Working distance(mm)	331	198	131	96	63	46
Field of view angle	19.5

Optical Magnification

Objective

0.3×

0.5×

0.75×

1.0×

1.5×

2.0×

Working

Distance

331mm

198mm

131mm

96mm

63mm

46mm

Eyepiece

Magni-fication

Field

of view

Magni-fication

Field

of view

Magni-fication

Field

of view

Magni-fication

Field

of view

Magni-fication

Field

of view

Magni-fication

Field

of view

0.35×

4.65×-31×

77-12mm

6×-41×

59-9mm

9×-61×

39-6mm

12×-81×

29-4mm

18×-121×

19.6-3mm

24×-162×

14.7-2mm

0.5×

7.8×-51×

46-7mm

10×-68×

35-5mm

15×-101×

23.5-4mm

20×-135×

17.6-3mm

31×-203×

11.8-2mm

41×-270×

8.8-1.3mm

0.75×

11.6×-77×

31-4.7mm

15×-101×

23.5-3.6mm

23×-152×

15.7-2.4mm

30.6×-202×

12-1.8mm

46×-304×

7.8-1.2mm

61×-405×

6-0.9mm

1.0×

15.5×-102×

23-3mm

20×-135×

17.6-2.7mm

30.6×-202×

12-1.8mm

41×-270×

9-16mm

1×-405×

6-0.98mm

1.6×-540×

4-0.7mm

1.5×

23×-154×

15-2.3mm

31×-203×

11.8-1.8mm

46×-304×

7.8-1.2mm

61×-405×

6-0.99mm

2×-607×

4-0.61mm

22×-810×

3-0.4mm

2.0×

31×-205×

11.6-1.7

41×-270×

8.8-1.3mm

61×-405×

6-0.9mm

81.6×-540×

4-0.71mm

22×-810×

3-0.41mm

63×-1080×

2-0.3mm

Standard Package

1. 1× Objective and 0.5×Eyepiece

2. Monocular microscope: Φ39mm, length: 200mm

3. Stand: 26cm×27cm×28cm

4. Package: 1 pc/carton, 30cm×31cm×52 cm, 4 kgs

Optional Accessories

1. Digital camera: BUC1-130C, BUC1-320C, BUC1-500C, BVC series and other digital cameras.

2. Illumination:

1) BAL-72 Ring LED Light

Specification

1. LED Q'ty: 72LEDs

2. Mounting Diameter: 62mm,Outer Diameter: 98mm

3. Input Power: DC12V 600mA

4. Input Voltage: Universal 100-240V AC

5. Output Power: 7.2W

6. LED Color Temperature: ±6500K

7. LED Luminance: >15000mcd

8. LED Angle: 18(Consistent)

9. LED Lifetime: 100,000 hrs

10. Working Distance: 95-115mm

11. LED Color: White(Optional Other Colors)

Features

1. Intensity Adjustment, Good Variable Control Permit Gradual Increase in Brightness with Four-zone Lighting Control Separately

2. Reliability and Durability

3. Low Power, Consumption, Super Brightness

4. Metal Shell, ESD and Insulativity

5. Reasonable Design, Uniformity Light, Non-flicker & Shadow

Standard Configuration:

72LED Lamp, Light Control Box, DC12V Power Supply

(2) Coaxial illumination device

Coaxial illumination device(Cold light illumination)

Coaxial illumination device (LED illumination device)

3. Adapter for Infinity metallurgical Objective Lens

Adapter and Infinity metallurgical Objective Lens

4. 3D attachment

With the 3D attachment, the objective can rotate 360, so the microscope can observe the objects from different view. This function is very useful in industrial inspection area.

5. Coarse and fine adjustment stand

Coarse and fine adjustment stand, large base, 330mm upright column.
